The Helo F1 disinfects a whole room, delivering protection from above. The unit can be ordered for installation in a drop-in grid ceiling, recessed in a hard ceiling, surface or wall mounted, or used as a portable, table top unit. It emits broad spectrum UV light to eliminate up to 99.9% 1 of the bacteria, viruses and fungi in a space. In rooms that have been cleaned of mold, the unit will help control return growth if used routinely.
Illumination
| Light Source | Proprietary Pulsed Xenon Lamp |
|---|---|
| Flash Interval | 1 UV Flash Every 6 Seconds |
| Wavelengths | UV-C (200-280nm) Germicidal UV-B (280-320nm) Germicidal UV-A (320-400nm) Antibacterial |
| Range | 10' x 10' typical (100sq feet) |
| UV Bulb Rated | > 2 Million UV Flashes* |
*Operating Life is dependent on frequency and duration of disinfection cycles.
Electrical System
| Input Voltage | 110V AC |
|---|---|
| Max Current | 3.5 Amps |
| Total Power | 25W per standard, 30 minute cycle |
| Power Connection | 3-prong grounded plug |
Physical
| Weight | F1 2.6 lbs |
|---|---|
| Housing/Finish | Brushed Aluminum |
| Optics | One patented UV Light Engine with transmissive UV lens and pulsed Xenon UV lamp |
| Beam Angle | 170° |
Environment
| Ambient Operating Temperature | 41° to 104°F |
|---|---|
| Ambient Operating Humidity | <80% RH non-condensing |
Certifications and Qualifications
| Safety | TUV Certified, tested to UL61010-12012 |
|---|---|
| FCC | Compliant with Part 15 Class A |
| RoHS | Compliant |
| FDA | Materials are approved for use in food and medical areas |
| EPA | Registered |
Variants
| Variant 1 | Helo Fixture Single UV Light Engine, No Flange, 6ft Plug, Manually or BACnet Commissioned, 110V |
|---|---|
| Variant 2 | Helo Fixture Single UV Light Engine, No Flange, 6ft Plug, Four 30-min Cycles/24-hrs, VESA Wall Mount Plate Included, 110V |
| Variant 3 | Helo Fixture Single UV Light Engine, 12.75 X 12.75 Flange, 6ft Plug, Manually or BACnet Commissioned, 110V |
| Variant 4 | Helo Fixture Single UV Light Engine, 24 X 24 Flange, 6ft Plug, Manually or BACnet Commissioned, 110V |
