Price does not include shipping fees.
Power & Efficiency
Input Power Options
- AC 1PH 200-240V 60Hz
- AC 3PH 200-240V 60Hz
- AC 3PH 380-480V 60Hz
Maximum Rated Current (amp)
- 3.0 - 2.5 A
- 4.3 - 3.6 A
- 8.2 - 6.8 A
Power (hp)
- 1 hp
Maximum Speed (RPM)
- 71 RPM
Max Affected Area
- 150 ft Dia | 22,500 sqft
Dimensions & Weight
Fan Diameter: 24 ft
Fan Weight : 204lb (93kg)
Mounting & Safety
Mounting Options
- I-beam
- Glulam
Downroad (A)
Downrods available in 1 ft increments: 2 ft min., 10 ft max.
Downrod length must be specified at time of order.
Safety Features
- Fan Retention System
- Airfoil Retention System
- Fire relay
In The Box
Included
- Fan I-beam mount with pre-wired downrod
- Control panel
- Install manual
- Mounting hardware kit
- Communication Kit
- Guy wire kit
Optional
- Additional cable lengths
- Touchscreen (5 in)
- Glulam brackets
Certifications
ETL/Intertek-certified to ANSI/UL 507 and CSA C22.2 No. 113 in North America
